IC693MDL742 Series 90-30
مشخصات IC693MDL742 SER 90-30 PLC GE FANUC
Rated Voltage
12/24 volts DC
Output Voltage Range
12 to 24 volts DC (+20%, –15%)
Outputs per Module
16 (two groups of eight outputs each)
Isolation
1500 volts between field side and logic side
500 volts between groups
Output Current t
1 amp maximum per point
4 amps maximum per group at @ 50 °C
3 amps maximum per group @ 60 °C
Output Characteristics
Inrush Current
5.2 amps for 10 ms
Output Voltage Drop
1.2 volts maximum
Off-state Leakage
1 mA maximum
On Response Time
2 ms maximum
Off Response Time
2 ms maximum
Power Consumption
Output Voltage Range
12 to 24 volts DC (+20%, –15%)
Outputs per Module
16 (two groups of eight outputs each)
Isolation
1500 volts between field side and logic side
500 volts between groups
Output Current t
1 amp maximum per point
4 amps maximum per group at @ 50 °C
3 amps maximum per group @ 60 °C
Output Characteristics
Inrush Current
5.2 amps for 10 ms
Output Voltage Drop
1.2 volts maximum
Off-state Leakage
1 mA maximum
On Response Time
2 ms maximum
Off Response Time
2 ms maximum
Power Consumption
130mA (all outputs on) from 5 volt bus on backplane
***موجود ، برای قیمت تماس بگیرید.
